Description
Table
- Welded sheet metal structure painted with epoxy powder
- Patient support table with 4-way mechanical brakes
- X-ray steel bucky tray
- Removable anti-scatter grid
- Inverter inside the table
Removable Anit-Scatter Grid
- Removable anti-grid 103 lines per inch
- 10:1 ratio
- Film focus disctance of 100cm
Collimator
- Radiation protection up to 125Kv
- Maual field setting
- Lamp timer 90 seconds – automatic start
- Field from 0 – 48x48cm
- LED light
Generator
- 110V power requirment
- Frequency: 50-60Hz
- Max Power: 30Kw
- Frequency Ripple: 40KHz
- Max Voltage: 125
- Max Power Supply: 400
- Exposure Time: 0.002 – 2 seconds
- X-ray Foot Switch: 6mt
Operating System
- Kv Setting: 40 – 125Kv
- mAs Setting: 0.6 – 80mAs
- 2 point technique: Kv – mAs
- 2 point technique: Kv – mAs – mS
- Anatomically programmed x-ray technique (APR)
- Focal spot selection
- Wight selection (kg)
- Thickness selection (cm)
X-ray Monobloc
- Power Supply: 11 – 30 Kw 40KHz
- X-ray tube rotating anode 2800RPM, 50Hz
- Anode Diameter: 60mm
- Focal spots 0.6 (11Kw) – 1.3 (30Kw)
- Radiation leakage is less than 3.5 micro Sv/h according to EN 60601-1-3
Optional
- X-ray hand switch
- Accessory with variable angle for myelography
