Description
Compact, Reliable Oxygen Generation for Veterinary Professionals
The Novair Compact-20B Oxygen Generator is a high-performance, plug-and-play oxygen generation system engineered specifically to meet the demands of veterinary practices. With 93% ±3% oxygen purity and continuous flow up to 20 SCFH (9.44 LPM), this system eliminates the need for cylinder deliveries—giving veterinary clinics greater control, autonomy, and reliability in oxygen supply.
Designed and manufactured in the USA, the Compact-20B is ideal for veterinary operating rooms, exam rooms, dental suites, and ICU areas. Its quiet operation and compact footprint make it easy to install even in space-constrained environments. Choose from vertical or horizontal configurations to best fit your clinic layout.
Key Benefits for Veterinary Practices
-
Continuous Oxygen Supply: Consistent, on-demand oxygen for surgeries, anesthesia machines, and emergency use.
-
Compact and Versatile Design: Available in vertical or horizontal units to suit various veterinary facility layouts.
-
Quiet Operation: Operates at just 68 dB(A), allowing it to be placed near treatment areas without disruption.
-
Energy-Efficient: Runs on a standard electrical outlet (115V or 230V) with no special wiring required.
-
Easy Maintenance: Durable shell, accessible components, and intuitive controls minimize service time.
-
Cost Savings: Eliminates recurring costs and delivery delays associated with oxygen cylinders.
Technical Specifications
-
Maximum Flow: 20 SCFH (9.44 LPM)
-
Output Pressure: Up to 85 PSI (5.9 bar)
-
Oxygen Purity: 93% ±3%
-
Sound Level: 68 dB(A) at 3 feet
-
Power Supply:
-
115 VAC / 60 Hz / 6A (1 Phase)
-
or 230–240 VAC / 50–60 Hz / 3A (1 Phase)
-
-
Operating Temperature: 40°F to 90°F (4.4°C to 32.2°C)
-
Dew Point: -60°F (-51°C)
-
Tank Size: 30 Gallons (114 Litres)
-
Weight: Approx. 220 lbs. (100 kg)
Unit Dimensions
-
Vertical Model (20B V): 19″ D × 69″ H × 24″ W
-
Horizontal Model (20B H): 17″ D × 46″ H × 40″ W
Typical Veterinary Applications
-
Surgical oxygen supply
-
Anesthesia equipment oxygen source
-
Post-operative recovery rooms
-
ICU and emergency oxygen support
-
Dental suite oxygen delivery
Installation Notes
The Compact-20B must be installed indoors in a temperature-controlled, well-ventilated room. Ideal for closet installations or utility rooms with ambient temperatures between 40°F and 90°F.
Boost operational efficiency, cut recurring cylinder costs, and ensure reliable oxygen delivery in your veterinary clinic with the Novair Compact-20B.
Contact us today to learn more or request a quote.
