Description
-
Dimensions (W × D × H): 16.9″W × 18.7″D × 7.1″H
-
Weight: 27.6 lbs
-
Max Power Output:
-
Monopolar: 400 W (at 200 Ω)
-
Bipolar: 400 W (at 75 Ω)
-
-
Output Frequency: 350 kHz / 1 MHz
-
Display: High-resolution interactive touchscreen with quadrant layout
-
User Interface: Customizable presets, effect settings, and personal favorites
-
Instrument Connections:
-
2 × Monopolar (3-pin & Bovie or Erbe compatible)
-
3 × Bipolar (2-pin or Erbe-compatible)
-
-
Advanced Features:
-
Plug’n Cut & Plug’n Cut COMFORT (auto instrument recognition)
-
SimCoag mode for dual bipolar instrument use*
-
LIGATION mode for vessel and tissue sealing*
-
Argon-assisted CUT and COAG with ARC PLUS add-on*
-
Dr. Dongle® for portable user settings
-
-
Safety Features:
-
EASY neutral electrode monitoring (with baby mode)
-
ISSys system self-testing
-
CCS initial cutting support
-
Current leakage and short-circuit monitoring
-
-
Connectivity: USB, network (LAN) socket
-
Power Supply:
-
Voltage: 100–127 V / 220–240 V
-
Frequency: 50/60 Hz
-
Max Power Consumption: 700 W / 1150 VA
-
*Optional features depending on configuration
